MYIR | System-On-Modules (SOMs)

MYC-C437X-V2

The MYC-C437X-V2 is a compact, feature-packed System-On-Module (SOM) powered by up to 1GHz TI AM437x Series ARM Cortex-A9 processors. Designed for industrial and automotive applications, it integrates 512MB DDR3 SDRAM, 4GB eMMC, and Gigabit Ethernet PHY. It offers excellent power management and connectivity, including support for dual CAN, serial ports, and dual camera interfaces. Ready to run Linux OS, it supports a wide operating temperature range from -40°C to +85°C..

  • Detail
  • Special Features
  • Specification

The MYC-C437X-V2 SOM is designed for high-performance embedded applications, offering a powerful 1GHz ARM Cortex-A9 processor. It integrates a 3D graphics accelerator and supports various industrial communication protocols like CAN, Ethernet, and more, making it an ideal choice for applications such as automotive systems, industrial control, and networking devices. It features a wide range of I/O, including dual USB 2.0, CAN bus, serial ports, and ADCs. With the flexibility of the dual camera and display processing subsystem, it is well-suited for HMI, industrial automation, and smart systems. The module’s compatibility with Linux OS and SYS/BIOS provides a reliable software platform for development.

  1. Processor: Up to 1GHz TI AM437x Series ARM Cortex-A9 processors (AM4376, AM4377, AM4378, AM4379).

  2. Graphics: POWERVR SGX Graphics Accelerator for 3D acceleration and display support.

  3. Memory:

    • 512MB DDR3 SDRAM

    • 4GB eMMC Flash (alternative designs with NAND Flash)

    • 32KB EEPROM

  4. Connectivity:

    • Gigabit Ethernet PHY

    • Dual USB 2.0

    • Dual CAN bus

    • Up to 6 Serial ports

    • 14 x ADC

  5. Operating System Support:

    • Linux 3.12.10, 4.1.18

    • SYS/BIOS 6.45 for TI-RTOS (for MYD-C437X-PRU)

  6. Temperature Range: -40°C to +85°C, ideal for industrial applications.

  7. Expansion Interface: Two 100-pin board-to-board expansion connectors.

  • Processor:

    • TI AM4376, AM4377, AM4378, AM4379 (up to 1GHz ARM Cortex-A9)

    • SGX530 Graphics Engine

    • Real-Time Unit (PRU-ICSS) for industrial protocols

  • Memory:

    • 512MB DDR3 SDRAM (supports up to 1GB)

    • 4GB eMMC (alternative designs with NAND Flash)

    • 32KB EEPROM

  • I/O Connectivity:

    • Gigabit Ethernet PHY

    • Dual USB 2.0

    • 6x Serial ports

    • 2x CAN

    • 2x SPI

    • 2x I2C

    • 14x ADC

    • 3x SDIO

    • Dual Camera Interfaces (MIPI CSI)

  • Expansion:

    • Two 100-pin board-to-board connectors

    • Display: RGB, LVDS (up to 2048 x 2048 pixels)

    • Power Management: TPS65218 IC

  • Operating System Support:

    • Linux 3.12.10, Linux 4.1.18

    • SYS/BIOS 6.45 for TI-RTOS (for MYD-C437X-PRU)

  • Temperature Range: -40°C to +85°C

  • Power Supply: 5V/0.33A
